DEEPCOOL CF120 3-IN-1 RGB

DEEPCOOL CF120 3-IN-1 RGB

Online Shop in Thailand
Categories: , Tag:

Customizable Addressable RGB LED Lighting

Utilize 12pcs of independently programmable RGB LED lights, CF120 provides full lighting for your build, achieving magical lighting effects with MB controls include 3 dynamic modes(waves, cycles and breathing) and 3 monochrome modes (constant light, breathing and meteor), up to 8 different colors to choose from

Synchronized Control via 5V A-RGB Header on MB

Can be easily controlled by MB through 5V A-RGB Header, no additional controller needed, and can synchronize with other A-RGB devices

Control by Using the Included A-RGB Controller
Use the included A-RGB Controller to control multiple Deepcool RGB devices, up to 6pcs
Better Balance on Performance & Low Noise
Better balance on air volume & air pressure, low noise, can be used as a case fan or CPU cooling fan

PWM Control

Super Silent

ADD-RGB LED

PWM Intelligent Control
Fan speed can be intelligently controlled by MB in accordance with temperature

Features

  • Utilize 12pcs of independently programmable RGB LEDs for amazing display effects
    *Can be easily controlled by MB through 5V A-RGB Header, no additional controller needed, and can synchronize with other A-RGB devices
  • Use the included A-RGB Controller to control multiple devices
  • Fan speed can be intelligently controlled by MB in accordance with temperature
  • Better balance on air volume & air pressure, low noise, can be used as a case fan or CPU cooling fan
    *WS2812B ADD-RGB LED is applied and the below 3pin ADD-RGB Headers are compatible for the device: 5V/D/G and 5V/D/NC/G, which is used for the mainstream M/B brands like ASUS, Gigabyte

Technical Spec

Fan Dimension 120×120×25mm
Net Weight 510g
FAN Speed 500±200~1500±10%RPM
Fan Air Flow 56.5CFM
Fan Air Pressure 1.63mmH2O
Fan Noise Level 17.8~27dB(A)
Fan Connector 4Pin
FAN Rated Voltage 12VDC
FAN Operating Voltage 10.8~13.2VDC
FAN Starting Voltage 7VDC
FAN Rated Current 0.11A
FAN Power Input 1.32W
Bearing Type Hydro Bearing
LED Type Addressable RGB LED
LED Rated Voltage 5VDC
LED Rated Current 0.48A
LED Rated Power 2.4W
LED Connector 3pin(+5V-D-G)
LED Control M/B with 5V ADD-RGB Header
EAN 6933412710332
P/N DP-FA-RGB-CF120-3

Product Dimensions
